Solis 4G PV Grid Tie Solar Inverter 2 MPPT 3 Phase 15kW 22/22A

Description

Solar Inverter, 3 Phase, 22.5 kW DC Input, 1000 Volt DC Input, 600 Volt DC Nominal, 160-850 Volt DC MPPT Voltage Range, 180 Volt DC Start-up, 22/22 Amp DC Max. Input, 2 MPPTs, 15 kW AC Output, 16.5 kVA AC Max. Apparent, 50/60 Hz AC Operating, 23.8 Amp AC Output, 0.8 Leading - 0.8 Lagging Power Factor, <1.5% Harmonic Distortion, 98.7% Efficiency, 98.1% European Weighted Efficiency, >99.5% MPPT Efficiency, Transformerless, 4000 mtr Max. Altitude, 4 Pins RS485 Connector Communication Port, LCD, 2 x 20 Z Display, Intelligent Fan-Cooling Cooling, <60 dBA, MC4/Terminal Connectors Connection, IP65, -25 to 60 deg C, 0-100% Relative Humidity, 563 mm Height, 310 mm Width, 219 mm Depth, 18.9 kg, IEC 62109-1, IEC 62109-2, AS 3100, EN 61000-6-1, EN 61000-6-2

Key Specifications

SKU	SOLIS-3P15K-4G
Brand	Solis
Product Type	Inverters

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Max. Efficiency 98.7% Integrate with adjustable Volt-Watt & Volt-Var Function Built-in DC-PV2 Switch comply with AS/NZS 5033 requirements THDi <1.5% Low Harmonic Distortion against grid DRM Integrated, fully comply with AS/NZS 4777.2:2020 2 MPPT Design with Precise MPPT Algorithm Integrated Export Power Management Voltage Active Power & Reactive Power Support 24h Consumption monitoring with a smart meter
Standard Pack Size	1
UNSPSC Class	26111600
UOM	EA
Vendor Product	SOLIS-3P15K-4G
AC Max. Apparent Power	16.5 kVA
AC Nominal Voltage	3/N/PE 230V/400V
AC Operating Frequency	50/60 Hz
AC Output Current	23.8 Amp
AC Output Power	15 kW
Communication Port	4 Pins RS485 Connector
Connection Type	MC4/Terminal Connectors
Cooling Method	Intelligent Fan-Cooling
DC Input Power	22.5 kW
DC Input Voltage	1000 Volt
DC Max. Input Current	22 Amp
DC MPPT Voltage Range	160-850 Volt
DC Nominal Voltage	600 Volt
DC Start-up Voltage	180 Volt
Depth	219 mm
Display Type	LCD 2 x 20 Z
Efficiency	98.70%
European Weighted Efficiency	98.10%
IP Rating	IP65
Height	563 mm
Item Weight	18.9 kg
Max. Operating Altitude	4000 Mtr
MPPT Efficiency	>99.5%
Noise Level	<60 dBA
Number of MPPTs	2
Operating Temperature	-25 to 60 deg C
Phase	3 Phase
Power Factor	0.8 Leading - 0.8 Lagging
Relative Humidity	0-100%
Topology	Transformerless
Total Harmonic Distortion	<1.5%
Width	310 mm
