Maser 1.5mm 2 Triad Instrumentation Cable Unarmoured Individual & Overall Screened

$Maser\Maser_MAU5602ESCS.jpg$

Description

Instrumentation Cable, Unarmoured, 1.5 mm, Stranded Annealed Copper, 110 Volt AC/150 Volt DC, 2 Triad, 7/0.5 mm Strands, Individual & Overall Screened Screen, 11.5 mm Overall Diameter, 115 mm Bend Radius, 13.6 Ohm/km Conductor Resistance, 0.4 mm Insulation Thickness, Aluminium/Polyester Foil Shield w/Tinned Copper Drain Wire Screen, Black/White Numerals Core, V-90 PVC Insulation, 5V-90 PVC Sheath, Black Sheath, -20 to 90 deg C, AS/NZS 1125 AS/NZS 3808 AS/NZS 1660

Key Specifications

SKU	MSRMAU5602ESCS
Brand	Maser
Product Type	Instrument Cable Unarmoured

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1000
UNSPSC Class	26121600
UOM	MTR
Vendor Product	MAU5602ESCS
Bend Radius	115 mm
Conductor Size	1.5 mm
Conductor Type	Stranded Annealed Copper
Core Colours	Black/White Numerals
Conductor Resistance	13.6 Ohm/km
Overall Diameter	11.5 mm
Number of Pairs	2 Triad
Insulation Thickness	0.4 mm
Insulation Material	V-90 PVC
Screen Format	Individual & Overall Screened
Sheath Material	5V-90 PVC
Standards	AS/NZS 1125 AS/NZS 3808 AS/NZS 1660
Screen Material	Aluminium Foil/Polyester Tape w/Tinned Annealed Copper Drain Wire
Sheath Colour	Black
Stranding	7/0.5 mm
Temperature	-20 to 90 deg C
Voltage	110 Volt AC/150 Volt DC
