E2S SONF1 Electronic Alarm Sounder 100 dB at 1 m 230 VAC Red Body

$E2S\E2S_SONF1_SON2_White.jpg$

Description

Electronic Alarm Sounder, 230 Volt AC, 13 mA, 100 dB at 1mtr, 10 Tones Sound, 2 Stage Alarm, 4 x M20 Knockout Connection, IP66, Flame Retardant ABS, Red Body, -25-55 deg C, 64.5mm x 86mm

Key Specifications

SKU	MECESS0018WX
Brand	E2S
Product Type	Audible Warning Devices

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	The SONF1 is a compact, high output, 100dB(A) alarm sounder Low current consumption and high SPL in a robust fire retardant housing ensure the SONF1 is suitable for all general signalling applications including fire, security and process control Continuous rating Two stage alarm (DC voltage only) by reversing polarity Automatic synchronization on multi-sounder systems Volume control
Standard Pack Size	1
UNSPSC Class	46171600
UOM	EA
Vendor Product	ESS0018WX
Alarm	2 Stage
Connection Type	4 x M20 Knockout
Colour	Red Body
Current	13 mA
Dimensions	64.5 mm x 86 mm
IP Rating	IP66
Material	Flame Retardant ABS
Sound Frequency	10 Tones
Sound Level	100 dB at 1 mtr
Voltage	230 Volt AC
Temperature	-25-55 deg C
