Longi Solar Panel 440W Monocrystalline 108 Cells Anodized Aluminum Alloy 25Years 39.83V 14.15A 25A 1500VDC 0.23 0-3%

$Longi_Solar\Longi_LR5-54HTB-440.JPG$

Description

Solar Panel, Monocrystalline Cell, 108, 440 Watt, 39.83 Volt Open Circuit, 14.15 Amp Short Circuit, 25 Amp Max. Fuse, 1500 Volt DC Max. System, 23% Efficiency, 0-3% Power Tolerance, 4 sq-mm, 1200 mm Length Output Cables, IP68 Junction Box, Anodized Aluminium Alloy Frame, -40 to 85 deg C Operating

Key Specifications

SKU	LONLR5-54HTB-440
Brand	LONGI
Product Type	Solar Panels

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	36
UNSPSC Class	26111600
UOM	EA
Vendor Product	LR5-54HTB-440
Cell Type	Monocrystalline
Certifications	IEC 61215 / ISO9001
Efficiency	23%
Frame Construction	Anodized Aluminium Alloy
Front Glass	Single 3.2 mm Coated Tempered
Height	30 mm
Item Weight	20.8 kg
Junction Box	IP68
Max. Fuse Current	25 Amp
Max. System Voltage	1500 Volt DC
Number Of Cells	108
Operating Temperature	-40 to 85 deg C
Power Tolerance	0-3%
Output Cables	4 sq-mm / 1200 mm Length
Temperature Coefficient	Isc: +0.050%/C /Voc:-0.230%/C / Pmax:-0.290%/C
Warranty	25 Years
Wattage	440 Watt
Width	1134 mm
