Garland RG59B/U Coaxial Cable 75Ohm 0.28mm 1/0.6mm Polyethylene/LSHF Black

Description

RG59B/U Coaxial Cable, 0.28 mm, Bare Copper, 0.6mm Conductor Diameter, Bend Radius: Install: 62mm, Tensile Strength: Before Aging >12 MPa, Stranding: 1/0.6mm, Insulation Thickness: 1.5mm, Sheath Thickness: 1mm, Conductor Resistance: DC: 62 Ohm/km at 20 deg C, 75 +/-3 Ohm Impedance, Bare Copper 84% Coverage Braid, Solid Polyethylene Insulation, LSHF Sheath, Black Sheath, 6.2mm Overall Diameter,-250 to 900 deg C

Key Specifications

Barcode (EAN-13)	9329849013714
SKU	GARCC59HF500
Brand	Garland
Product Type	Coax Cable

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	500
UNSPSC Class	43221700
UOM	MTR
Vendor Product	CC59HF500
Bend Radius	Install: 62mm
Braid Material	Bare Copper 84% Coverage
Conductor Resistance	DC: 62 Ohm/km at 20 deg C
Conductor Diameter	0.6mm
Conductor Size	0.28 mm
Conductor Type	Bare Copper
Insulation Material	Solid Polyethylene
Insulation Thickness	1.5mm
Overall Diameter	6.2mm
Sheath Colour	Black
Sheath Material	LSHF
Sheath Thickness	1mm
Stranding	1/0.6mm
Temperature	-250 to 900 deg C
Tensile Strength	Before Aging >12 MPa
