Canadian Solar Solar Inverter 600V 1 Phase 6500W 50/60Hz 5 Years
Loading...
Description
Solar Inverter, 1 Phase, 6500 Watt DC Input, 600 Volt DC Input, 360 Volt DC Nominal, 100-550 Volt DC MPPT Voltage Range, 110 Volt DC Start-up, 12/12 Amp DC Max. Input, 2 MPPTs, 5000 Watt AC Output, 5500 Watt AC Max. Apparent, 220/230/240 (180-280) Volt AC Nominal, 50/60 Hz AC Operating, 25 Amp AC Output, >0.99 Power Factor, <3% Harmonic Distortion, 98% Efficiency, 97.5% European Weighted Efficiency, 99.9% MPPT Efficiency, Transformerless, 4000 mtr (Derating Above 3000 mtr) Max. Altitude, Integrated DC Switch, M16 (WIFI/RS485/GPRS Optional) Communication Port, LED Indicator Display, Natural Convection Cooling, <25 dBA, DC Connection: MC4/H4, AC Connection: Connector Connection, Wall Mounting, IP65, -25 to 60 deg C (Derating Above 45 deg C), 0-100% Relative Humidity, 435 mm Height, 355 mm Width, 158 mm Depth, 13.5 kg, IEC 62109-1/2, IEC 61000-6-1, IEC 61000-6-3, 5 Years Standard, Extention up to 10 Years Warranty
Key Specifications
| SKU |
CASCSI-5K-S22002-E
|
|---|---|
| Brand |
Canadian Solar
|
| Product Type |
Inverters
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 1 |
|---|---|
| UNSPSC Class | 26111600 |
| UOM | EA |
| Vendor Product | CSI-5K-S22002-E |
| AC Max. Apparent Power | 5500 Watt |
| AC Nominal Voltage | 220-230-240 (180-280) Volt |
| AC Operating Frequency | 50/60 Hz |
| AC Output Current | 25 Amp |
| AC Output Power | 5 kW |
| Communication Port | M16 (WIFI/RS485/GPRS Optional) |
| Connection Type | DC Connection: MC4/H4 AC Connection: Connector |
| Cooling Method | Natural Convection |
| DC Input Power | 6500 Watt |
| DC Input Voltage | 600 Volt |
| DC Max. Input Current | 12 Amp |
| DC MPPT Voltage Range | 100-550 Volt |
| DC Nominal Voltage | 360 Volt |
| DC Start-up Voltage | 110 Volt |
| DC Switch | Integrated |
| Depth | 158 mm |
| Display Type | LED Indicator |
| Efficiency | 98% |
| European Weighted Efficiency | 97.50% |
| IP Rating | IP65 |
| Height | 435 mm |
| Max. Operating Altitude | 4000 mtr (Derating Above 3000 mtr) |
| Mounting Method | Wall |
| MPPT Efficiency | 99.90% |
| Noise Level | <25 dBA |
| Number of MPPTs | 2 |
| Operating Temperature | -25 to 60 deg C (Derating Above 45 deg C) |
| Phase | 1 Phase |
| Power Factor | >0.99 |
| Relative Humidity | 0-100% |
| Topology | Transformerless |
| Total Harmonic Distortion | <3% |
| Width | 355 mm |
