Clipsal Cortex Solar Monitoring Energy Meter 2x24AWG 1.2W 80-265V 60A IP50 45-65Hz 4G/Pentaband/LTE/3 Dry Contact 0.3kg

$Clipsal_Cortex\Clipsal_Cortex_CX1.jpg$

Description

Solar Monitoring Energy Meter, 80-265 Volt, 60 Amp, 1.2 Watt Power Consumption, 45-65 Hz, 2 x 24 AWG Conductor, 4G, Pentaband, LTE, 3 Dry Contact Connector, DIN Rail Mounting, IP50, -10 to 55 deg C, 89 x 77 x 35 mm, 0.3 kg Item Weight

Key Specifications

SKU	CLCCX1
Brand	Clipsal Cortex

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Export Limiting: Communication via Modbus for solar export limiting and batteries Intelligent Control: Control channels excess solar to heavy load appliances Advanced Monitoring: Understanding energy usage through an award-winning app and tailored insights from a battery calculator and more
Standard Pack Size	20
UNSPSC Class	26111600
UOM	EA
Vendor Product	CX1
Conductor Size	2 x 24 AWG
Connector System	4G / Pentaband / LTE / 3 Dry Contact
Current	60 Amp
Dimensions	89 x 77 x 35 mm
IP Rating	IP50
Frequency	45-65 Hz
Mounting Method	DIN Rail
Item Weight	0.3 kg
Power Consumption	1.2 Watt
Temperature	-10 to 55 deg C
Product Type	simple
Voltage	80-265 Volt
