SFR SFRSE4 RCBO 3P+N 10kA 40A D Curve 30mA Type A with Leads

Description

RCBO, 40 Amp, 415 Volt AC, 50/60 Hz, 10 kA Interrupt Capacity, 30 mA Trip Sensitivity, 3 Pole + N Pole, D Curve, Thermal Magnetic Operator, Pillar Type Terminal, IP20, Black Handle,-5 to 55 deg C, 113.5mm Height, 53.4mm Width, 77.2mm Depth

Key Specifications

SKU	SFRSE4ND40
Brand	SFR
Product Type	Combination RCBO

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Provides overload, short circuit and earth leakage protection Provides protection in the event of direct/indirect contact by the human body Provides comprehensive protection to industrial and commercial distribution system Provides protection against insulation failure Suitable for applications with a neutral Handle is sealable and padlockable
Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	SFRSE4ND40
Colour	Black Handle
Current	40 Amp
Depth	77.2 mm
Height	113.5 mm
Frequency	50/60 Hz
IP Rating	IP20
Interrupt Capacity	10 kA
Number Of Poles	3 Pole
Terminal Connection	Pillar Type
Temperature	-5 to 55 deg C
Trip Characteristic	D Curve
Voltage	415 Volt
Trip Sensitivity	30 mA
Width	53.4 mm
