Clipsal 56 Series Plug Straight Body Weatherproof 1Ph 10A 110V 3 Pin Round Flat Earth Grey IP66
Loading...
Description
Plug Straight Body Weatherproof, Angle: Straight, 1 Phase, 10 Amp, 110 Volt AC, 3 Pin Round Flat Earth, Grey, IP66, Screw, Terminal Capacity: 0.75 to 1 mm, Cable Gland, M20 Cable Gland, PBT, -25 to 75 deg C, 67 mm Height, 67 mm Width, 112.5 mm Depth
Key Specifications
| Barcode (EAN-13) |
9311554071523
|
|---|---|
| SKU |
CLI56P3/110GY
|
| Brand |
Clipsal
|
| Range Name |
56 Series
|
| Product Type |
Plugs Straight
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 1 |
|---|---|
| UNSPSC Class | 39121400 |
| UOM | EA |
| Vendor Product | 56P3/110-GY |
| Angle | Straight |
| Cable Entry | Cable Gland |
| Cable Gland Size | M20 |
| Connection Type | Screw |
| Colour | Grey |
| Current | 10 Amp |
| Depth | 112.5 mm |
| Height | 67 mm |
| IP Rating | IP66 |
| Phase | 1 Phase |
| Pin Configuration | 3 Pin Round Flat Earth |
| Temperature | -25 to 75 deg C |
| Terminal Capacity | 0.75 to 1 sq-mm |
| Voltage | 110 Volt |
| Width | 67 mm |
