ASI Lamps Type 97 Sub-Miniature Lamp T1 5V 115mA Wire Tail 0.15 MSCP 20000 hrs C2R Filament 3x20mm
Loading...
Description
Indicator Lamp, Sub-Miniature, T1, 5 Volt, 115 mA, Wire Tail Base, 0.15 MSCP, 20000 hrs Average Life, C2R Filament, 3 mm Overall Diameter, 20 mm Overall Length
Key Specifications
| SKU |
ASS97-005/115
|
|---|---|
| Brand |
ASI Lamps
|
| Range Name |
Type 97
|
| Product Type |
Indicator Lamps Sub-Mini
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 1 |
|---|---|
| UNSPSC Class | 39121500 |
| UOM | EA |
| Vendor Product | 097-005/115 |
| Average Lamp Life | 20000 hrs |
| Base Type | Wire Tail |
| Current | 115 mA |
| Diameter | 3 mm |
| Filament | C2R |
| Lamp Shape | T1 |
| MSCP | 0.15 MSCP |
| Voltage | 5 Volt |
Downloads
