Wilco Switch Socket Outlet Surface Mounting Metal Clad 3Ph 32A 500V 4 Pin Round Yellow/Blue Switch IP66

Description

Switch Socket Outlet Surface Mounting Metal Clad, 3 Phase, 32 Amp, 500 Volt, 4 Pole, 2 Gang, 4 Pin Round, Screw, Terminal Capacity: 4 to 16 mm, Surface Mount, IP66, Cast Aluminium, Yellow, Blue Switch, 258 mm Height, 115 mm Width, 120 mm Depth, -20 to 70 deg C

Key Specifications

Barcode (EAN-13)	9311554122744
SKU	WILWMC432
Brand	Wilco
Range Name	A Series
Product Type	Switch Sockets

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Spring loaded socket flap with latch for added safety coverage Off and On marking is raised to ensure marking never wears off Padlocking facility (8 mm) in off position Optional safety interlock facility External and accessible mounting facilities 316 stainless steel cover mounting screws
Standard Pack Size	1
UNSPSC Class	39122200
UOM	EA
Vendor Product	WMC432
Colour	Yellow/Blue Switch
Connection Type	Screw
Current	32 Amp
Depth	120 mm
Height	258 mm
IP Rating	IP66
Mounting Method	Surface
Number Of Poles	4 Pole
Phase	3 Phase
Pin Configuration	4 Pin Round
Temperature	-20 to 70 deg C
Terminal Capacity	4-16 mm
Voltage	500 Volt
Width	115 mm
