Terasaki TemBreak Pro Moulded Case Circuit Breaker 70kA 3 Pole 690/250 Volt AC/DC 12.5-20 Amp Adj Thermal Magnetic

Description

Moulded Case Circuit Breaker/690/250 Volt AC/DC/20 Amp/50/60 Hz/70 kAinterrupt Capacity/3/12.5-20 Amp Adjustable Thermal Setting/120-240 Amp Magnetic Setting/160 Frame Frame/Thermal Magnetic/Screw Terminal/Panel Mounting/-5 to 70 deg C/130mm Height x 90mm Width x 95.5mm Depth

Key Specifications

SKU	TERP160H2320TM
Brand	Terasaki
Range Name	TemBreak Pro
Product Type	MCCBs

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	P160H2320TM
Current	20 Amp
Depth	95.5 mm
Frame Type	160 Frame
Frequency	50/60 Hz
Height	130 mm
Interrupt Capacity	70 kA
Magnetic Setting	120-240 Amp
Mounting Method	Panel
Number Of Poles	3 Pole
Temperature	-5 to 70 deg C
Terminal Type	Screw
Thermal Setting	12.5-20 Amp Adjustable
Trip Type	Thermal Magnetic
Voltage	690 Volt AC/250 Volt DC
Width	90 mm
