SFR Electro Magnetic RCBO Circuit Breaker 2Pole 40 Amp 240V AC 6 kA DIN

Description

Electro Magnetic RCBO Circuit Breaker Compact, 40 Amp, 240 Volt AC, 50/60 Hz, Interrupt Capacity: 6 kA, Trip Sensitivity: 30 mA, Number of Poles: 2, Trip Characteristic: C Curve, 25 mm Terminal Connection, IP20, DIN, 87.5mm Height, 74mm Width, 35.6mm Depth

Key Specifications

SKU	SFRSE8C40
Brand	SFR
Product Type	Combination RCBO

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Complies with latest ESV requirements for RCBOs Provides overload, short circuit and earth leakage protection Provides protection against insulation failure Positive contact indication Handle is sealable and padlockable (with padlock attachment)
Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	SFRSE8C40
Current	40 Amp
Depth	35.6 mm
Height	87.5 mm
Frequency	50/60 Hz
IP Rating	IP20
Interrupt Capacity	6 kA
Mounting Method	DIN Rail
Number Of Poles	2 Pole
Terminal Connection	25 sq-mm
Trip Characteristic	C Curve
Voltage	240 Volt
Trip Sensitivity	30 mA
Width	74 mm
