Heinelec Combination RCD Circuit Breaker RCBO 2 Pole (1 Ph+N)Pole 32 Amp 110 to 240V AC 6 kA 1Module 25.8mm Surface/Base

Description

Combination RCD Circuit Breaker RCBO, 110-240 Volt, 32 Amp, 50/60 Hz, 6 kA Interrupt Capacity, 30 mA Trip Sensitivity, 2 + N Pole, 1 Module 25.8 mm, 0.75 to 35 sq-mm Terminal, Shrouded Line and Load Connection, IP2X, Surface/Base Mounting, 40 to 85 deg C, 149 mm Height, 76 mm Width, 71.8 mm Depth

Key Specifications

SKU	HEISF1EL32-3
Brand	Heinelec
Range Name	SF1EL
Product Type	Combination RCBO

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Provides 30 mA residual current protection Switches both the active and neutral poles Hydraulic magnetic RCBO Overcurrent trip point unaffected by ambient temperature Immune to pulsating DC Earth leakage sensitivity 10-30 mA Single Pole pluse switched netural earth leakage protection Additional netural wire Precision tripping characterstics Trip indication with mid trip position
Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	SF1EL32-3
Current	32 Amp
Connection Type	Shrouded Line and Load
Height	149 mm
Depth	71.8 mm
Modules	1 Module 25.8 mm
Frequency	50/60 Hz
Interrupt Capacity	6 kA
Mounting Method	Surface/Base
IP Rating	IP2X
Number Of Poles	2 Pole
Temperature	40 to 85 deg C
Terminal Connection	0.75 to 35 sq-mm
Trip Sensitivity	30 mA
Voltage	110-240 Volt
Width	76 mm
