Bambach SafeX125 High Temperature SDI Flexible Wire 1 Core 16mm 0.6/1kV X-HF-110/HFS-110-TP Blue

Description

Flexible Wire, Double Insulated, High Temperature, 1 Core, 16 mm, Class 5 or 6 Oxygen Free Tinned Annealed Copper, 0.6/1 kV, 135 Amp, 224/0.3 mm Strands, 9.3 mm Overall Diameter, 55.8 mm Bend Radius, X-HF-110 Insulation, HFS-110-TP Sheath, Natural Core, Blue Sheath, -40 to 125 deg C, AS/NZS 1125, AS/NZS 3808, AS/NZS 5000.1, AS/NZS 1660.5.6, IEC 60228, IEC 60332-1

Key Specifications

SKU	BAM26800BES
Brand	Bambach
Product Type	Flexible Cable High Temperature Double Insulated

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Up to 50% higher current ratings compared to PVC flexible cable Reduced overall diameters compared with PVC flexible cable Cross-linked insulation and sheath form a stronger structure and do not melt or flow when heated Oxygen free tinned copper for high conductivity soldered connections and corrosion protection RoHS compliant to comply with European environmental requirements Cross-Linked- Insulation and sheath are fully cross-linked to enhance performance Low Smoke- Reduced smoke emission in a fire situation Low Toxicity- Reduced toxicity in a fire situation Non-Corrosive- No corrosive gas emission in a fire situation High Temperature Rating- 125 deg C temperature rating allows for higher current carrying capacity
Standard Pack Size	10
UNSPSC Class	26121600
UOM	MTR
Vendor Product	26800BES
Bend Radius	55.8 mm
Conductor Type	Class 5 or 6 Tinned Annealed Copper
Conductor Size	16 mm
Core Colours	Natural
Current	135 Amp
Insulation Material	X-HF-110
Sheath Colour	Blue
Overall Diameter	9.3 mm
Number of Cores	1 Core
Sheath Material	HFS-110-TP
Standards	AS/NZS 1125 AS/NZS 3808 AS/NZS 5000.1 AS/NZS 1660.5.6 IEC 60228 IEC 60332-1
Stranding	224/0.3 mm
Temperature	-40 to 125 deg C
Voltage	0.6-1 kV
